Automatic Single Side 18650 Battery Pack Spot Welder Welding
Machine
Product Description
This machine is used for 18650 battery pack automatic spot welding,
it can weld both side together with high speed and good effect.
Product Features
1. Support breakpoint start, support automatic start and manual
start mode conversion.
2. It has a false spot welding and out of spot welding alarm
function.
3. Programming is simple, and it supports any point programming and
array programming. 999 groups can be saved programming files.
4. Welding needle replacement forecast reminder.
5. Own welding current monitoring system, real-time monitoring of
welding current.
Product Application
With the customized fixture jig, the spot welding machine can weld
18650, 26650, 32650 and other cylindrical battery pack, can also be
customized for a variety of cylindrical battery, square battery,
button battery and etc.
Product Stucture
Product Specification
| Item | Parameter |
|---|
| Welder | 5000A/8000A inverter spot welding power supply(optional) |
| Welding head quantity | 1 |
| Welding range | 400*400mm |
| Cell type | 18650, 21700, 32650… all types of cylinderial cells |
| Total cell support | 300-600 pcs |
| Welding speed | Max 0.35s/spot, 2800 pcs/h |
| Cell link material | Nickel, Nickel-Plated Steel |
| Welding max thickness | 0.3mm |
| Max parameter groups | 99 groups |
| Operation system | Microcomputer and touch screen user interface |
| Driver mode | Motro and precision guide rail |
| Cooling method | By air or water (optional) |
| Air pressure | 0.4-0.6 Mpa |
| Power voltage | Single phase 220V/Three phase 380V |
| Power | 8000 W |
| Size | 900L*900W*1930Hmm |
| Weight | 300kg |
Product Details
Battery Pack Welding Samples
Spot welding samples
The double side spot welding machine suitable for all types of
cylindrical cells pack and suitable for all shapes of packs. With
high quality 5000A/8000A spot welding power supply, it can weld
thickness from 0.1mm to 0.3mm. Welding spot is beautiful, firm and
good conductivity.
