Semi Automatic 8000A Double Sides Spot Welding Cylindrical Lithium
Battery Spot Welding Machine
Product Description
The Automatic Battery Pack Spot Welder is a general platform of
automatic processing technology based on CNC, suitable battery pack
spot welding and assembly in the factory. Compared with manual spot
welding machine, the efficiency and accuracy of welding have been
greatly improved. Humanized design makes the operation and
debugging very easy and convenient. Design of components built-in
makes appearance more concise. We can also offer CNC welding
machine. Welcome your inquiry to us for more details.
Product Features
1. Support break point start, support automatic start and manual
start mode conversion.
2. It has a false spot welding and out of spot welding alarm
function.
3. Programming is simple, and it supports any point programming and
array programming. 99 groups can be saved programming files.
4. Welding needle replacement forecast reminder.
5. Own welding current monitoring system, real-time monitoring of
welding current.
6. Suitable for electric car battery, car battery module, balance
the car battery, scooter battery, mobile power supply, start the
battery module, power tools batteries, laptop batteries, etc.
Various battery combinations!
7. The welding efficiency is about 8 times higher than that of
manual workers, with high stability, labor saving and time saving.
Product Advantages
1) Induce load voltage, control voltage by feedback, and realize
high quality welding.
2) Preheat, Main Heat's power mode, preheating before welding, to
ensure stable welding quality.
3) Keep the continuity of energy density, shorten the welding time,
and reduce the deformation and color of base metal. (Welding time
controlled in microseconds, continuous output mode)
4) Easy to change from low current to high current, suitable for
precision welding.
5) The upper and lower limits of current can be set to simply judge
whether the welding quality is good or not, which is suitable for
welding automation platform.
6) The welding current rises with the time of electrification to
ensure the welding effect.
Product Specification
X-axis stroke | 500mm (customizable) | Operating system | Embedded system + HMI |
Y-axis travel | 350mm (customizable) | Transmission mode | Screw rod+precision linear guide rail |
Max spot welding rate | 0.5S/point; 1500-1800pcs/h | Driving mode | Hybrid servo motor |
Max speed of motor drive | 1500mm/S | Nickel welding thickness | 0.1mm-0.3mm |
Max loaded cell (18650) | About 500pcs (20 * 25) | Dimension | 900L*1100W*1930H |
No. of file groups saved | 99 groups | Positioning accuracy | ±0.02mm |
Weight | 300KG | Horizontal bearing weight | 35kg (OEM) |
Product Application
Power Battery 18650 / 26650 series-parallel combination of
batteries, multi-parallel multi-series combination, electric tool
battery, torsion car battery (1 die spot welding 6 groups) , energy
storage battery pack, 18650 Battery Group, 26650 Battery Group,
32650 Battery Group, Electric Bicycle Battery, solar Street light,
Ternary Lithium Ion battery, digital lithium ion battery, lithium
iron phosphate battery, etc. .
Product Operation
1. Setting the parameters of welding on the touch screen. (The same
product only need to be set once)
2. Put the fixture with the battery pack on the quick clamping
position.
3. Press the start button, MD-ADW automatically complete all
welding actions.
4. MD-ADW sound to prompt operator replacement of new fixture
(battery pack).
Spot welding machine details
