3-Axis Laser Welding Machine for Prismatic Battery Pack Welding

Description

Laser welding a high efficient precision welding method which is in the use of high energy density laser beam as a heat source .due to its unique advantages, It has been successfully applied to the precision welding of power battery pack and various metal articles.

Features

1. This machine uses CW fiber laser, which has high electro-optical conversion efficiency and long laser life;
2. The laser beam quality is excellent and the welding speed is fast, which is more than 5 times the speed of the traditional optical fiber transmission laser welding machine. The welding seam is thin, the depth is large, the taper is small, and the precision is high. It can fully meet the needs of users in different industries and has a firm appearance. Smooth and beautiful;
3. The whole machine has low energy consumption, maintenance-free, high stability, long-term use can save users a lot of processing costs;
4. The control system is a professional three-axis control system tailored for laser welding. It has powerful PC control, easy to program, debug and maintain. It can complete automatic or semi-automatic spot welding, butt welding, stitch welding, and sealing welding. Welding of complicated plane straight lines, arcs and arbitrary trajectories; high stability, strong expansibility, easy to learn, understand and use;

Structure

Laser Welding Machine

Details

Industrial Computers and High-Performance Fiber Laser Generator

Operation Buttons

Connectors

Welding samples

Laser Welding Machine Battery Pack Weldling Samples

Parameters

Packing

Our project

India project
This project is localed in Inda, Gurgaon. The client was founded in 1994, have more than 400 staffs and 10000+ square factory.

They bought 2 full of battery pack assembly line from us, includes sorting machine, welding machine, sticking machine, charge and discharge machine…
We have sent 3 engineers to client site for machine installation and training in year of 2019. The training taked about one week. After the training, the client engineers are learned how to operation the machines in a smooth and high efficiency way. They made high-quality products by our machines.
We had a nice journey in India.
